Detailed Technical Analysis of EMOTET Malware Campaign Attack

EMOTET Malware Campaign Overview

Recently a new malware campaign has been seen in the wild across the globe, in which an attacker is sending phishing emails with malicious links or an attachment of Office Document in the Email.

In case, if the Email contains a malicious link then it downloads the malicious office document when the person clicked on it.

In another scenario, Email contains an attachment of malicious office document.

In both the scenario, the malicious document contains an obfuscated malicious macro script that automatically downloads the EMOTET malware on the user’s machine.

Flow Chart:

Get peace of mind! Get rid of malicious programs instantly

Free Malware Scan Compatible with Win 10,8.1,8 & 7

Technical Analysis of EMOTET Malware Campaign

File Name: INV654135635008082.doc

MD5: 9E88441722CDE0C95F613A96B8554705

File Type: DOC

Spread Via:  E-mail

Detail Description EMOTET Malware Campaign with Screenshots

During execution of INV654135635008082.doc, it’s launch Microsoft Word application in Protected View Mode.

Figure 1 Enable Editing (Protected View Mode)

By default, Microsoft Office Application has turned on the Protected Mode Feature & Also Disabled the Macro’s for security purposes.

In case, if the user disabled the protection mechanism & enabled the macro’s feature then the warning message notification doesn't pop up. And it will harm your system.

So, it’s always recommended to never disable the protection mode.

As shown below, After Enable Editing, it shows another warning message (“Macros have been disabled”).

Figure 2 Enable Content Warning

In case, if the user clicks on the Enable Content button or doesn’t use Microsoft Default Protected View Mode, the Malicious macro will automatically download the payload into %temp% location with the help of Powershell.exe

%temp%\{Random-ID}.exe

As shown below, WINWORD.exe creates several processes

Figure 3 Process Tree

As shown below, INV654135635008082.doc contain obfuscated malicious macro which is not clearly visible and understandable by the normal user.

Below macro code has Sub Document_Open() function which means on opening the document, the malicious macro code will be get activated.

Figure 2 Obfuscated Macro Code

To understand the obfuscated code, a person needs to be expertise or having the skillset to deobfuscate this kind of obfuscated code.

By analyzing the above obfuscated macro code, we came to know that it's running the malicious obfuscated PowerShell script in the background.

Figure 3 Obfuscated PowerShell Script

As shown above, this PowerShell script contains another obfuscated code.

Deobfuscated PowerShell script:

Figure 4 Deobfuscated PS Script

Also See: Detailed Technical Analysis of Jigsaw Ransomware Attack

As shown above, PowerShell script attempts to connect 5 URL’s, whichever URL is active it downloads the payload into %temp%\{Random-ID}.exe

Thereupon, it automatically starts the downloaded payload process (Random-ID.exe) on the victim’s machine.

From the above 5 URL’s, only 2 URL’s are active yet rest of the URL’s are not working now. And all of them will downloads the same malware payload (EMOTET HASH: 17A8054EDBF3C8B5ABFD3A1EFB8A016B)

This malware then dropped another file at following location

C:\Users\admin\AppData\Local\Microsoft\Windows\fonduexinput.exe

fonduexinput.exe (MD5: BA963C5B203753F9BF04CFBBFFC1F5B4) tries to connect with their C&C Server 96.94.189.130

It also creates an autorun entry in the registry at following location:

HKEY_CURRENT_USER\Software\Microsoft\Windows\CurrentVersion\Run\fonduexinput

Following are the MUTEXES created by the fonduexinput

M2A5B3DF7

PEMF48

IOC’s

Associated Hash

9E88441722CDE0C95F613A96B8554705

17A8054EDBF3C8B5ABFD3A1EFB8A016B

BA963C5B203753F9BF04CFBBFFC1F5B4

Associated URL

hxxp://www[.]storiesofsin[.]com/themes/sos/images/Yec23

hxxp://www[.]logopeda-slonecznik[.]pl/pv6j24/

hxxp://www[.]vanchuyencontainerlanh[.]com/78TGV/

hxxp://www[.]whattrick[.]com/MffufXs/

hxxp://www[.]muccimobilya[.]com/pwz0/

Associated IP

96.94.189.130

Associated MUTEXES

M2A5B3DF7

PEMF48

Associated Registry Entry

HKEY_CURRENT_USER\Software\Microsoft\Windows\CurrentVersion\Run\fonduexinput
